SOUTH BEND 9″ & 10K “Light 10” Metal Lathe Parts Manual and Catalog 0674
Manual Description:Number of Pages: 42 This is a reproduction, not a photocopy, of a South Bend Parts Manual and Catalog for 9″ & 10″ Lathes. I included a short descriptive catalog to help identify which lathe a person has, because there were many different models. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams.. This manual will help you with setting up and running a South Bend 9″ & 10″ Lathe. These are some of the lathes covered in this manual: Gear Box: Some of the lathes made for the time frame covered by this manual were made without gear boxes for threading, but some did have a gear box. Below is a picture of the gear box that was used in this time frame. Contents: Catalog Catalog 9-HE……………………………1-6 Maintenance Introduction……………………………..7 Headstock Spindle Sleeve Bearings………..8-10 Assemble Headstock…………………….10-11 Checking and Lubricating Headstock…………11 Back Gear and Eccentric Shaft……………..12 Operations Thread Gears for 27 Threads Per Inch…….13-14 Adjusting Toggle Cam Apron Clutch………….15 Remedy a Sticky Clutch……………………16 Cutting Tool Data………………………..17 Cutting Bit Grinding Block………………..18 Parts Lists and Diagrams……………….19-40 Overview: I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.Visit our eBay Store!We have over 1,100 manuals available. From our shop to yours. We get this. But you get this! Why settle for anything less?We can’t make pictures a lot better than the original, but we can fix everything else. Shipping: We ship every M-T-W-T-F except US holidays. All of our manuals are shipped with Delivery Confirmation. We stamp “Do Not Bend” on them to ensure that your manual arrives quickly in good condition. Any package that weighs more than 15.9 oz cannot be shipped First Class, and will be shipped Media Mail. Priority and Express mail options are available to purchase. Since we offer free shipping, we cannot reship manuals for free, due to inaccurate or insufficient addresses. Reshipping Fees for inaccurate or insufficient addresses: $5.00 for the first manual and $2.50 for each additional manual. Service: We have been providing this service to fellow craftsman and machinist for over 20 years. We treat everyone as we would like to be treated. We try to take care of all our customers. We do more than sell manuals, we have a complete woodworking and machine shop. We operate all kinds of machinery everyday.
