ROCKWELL-DELTA 20″ Drill Press Owners Operators Parts Manual 0641
Manual Description:Number of Pages: 12 This is a reproduction, not a photocopy, of an original Delta-Rockwell 20″ Drill Press Parts Manual. This drill press has DP1171 casting for the drill press head. This parts manual covers a lot of the accessories that are not normally covered in a standard parts manual. This is very important, because many of the Rockwell 20″ drill press models have several accessories on them because they were used in production industries like the powerfeed, mortising attachment, etc… This manual contains explosive view diagrams of all the parts with parts descriptions.. I also highly recommend the “DELTA Getting the Most Out of Your Drill Press Manual”, which we carry. It covers a lot of different set ups and unique uses for these drill presses. Contents: Hand-Feed Head, Belt Guard, and Motor Pulley………1,2 Hand-Feed Head…………………………………..3 Motor Plate……………………………………..4 Power-Feed Head, Belt Guard, and Motor Pulley……..5,6 Power-Feed Head………………………………..7,8 Power-Feed Components…………………………….9 Elevating Unit…………………………………..9 Mortising Attachment and Hold-Down………………..10 Tilting Table…………………………………..10 Column and Cradle……………………………….11 Miscellaneous Accessories………………………..12 Overview: I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.Visit our eBay Store!We have over 1,100 manuals available. From our shop to yours. We get this. But you get this! Why settle for anything less?We can’t make pictures a lot better than the original, but we can fix everything else. Shipping: We ship every M-T-W-T-F except US holidays. All of our manuals are shipped with Delivery Confirmation. We stamp “Do Not Bend” on them to ensure that your manual arrives quickly in good condition. Any package that weighs more than 15.9 oz cannot be shipped First Class, and will be shipped Media Mail. Priority and Express mail options are available to purchase. Since we offer free shipping, we cannot reship manuals for free, due to inaccurate or insufficient addresses. Reshipping Fees for inaccurate or insufficient addresses: $5.00 for the first manual and $2.50 for each additional manual. Service: We have been providing this service to fellow craftsman and machinist for over 20 years. We treat everyone as we would like to be treated. We try to take care of all our customers. We do more than sell manuals, we have a complete woodworking and machine shop. We operate all kinds of machinery everyday.
