DELTA-MILWAUKEE 14″ Drill Press DP-220 Owners Instructions & Parts Manual 0239
Manual Description:Number of Pages: 11 This is a reproduction, not a photocopy, of an original Delta-Milwaukee 14″ Drill Press with DP-220 Head Casting Operating and Maintenance Instructions. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with cross-sectional view diagrams. This manual has information on motor speeds as well as a diagram of the bearing setup on the spindle/quill. Another important thing contained in this manual is how to adjust the spindle-return spring, which controls the quill. We’ve included the pages from the sales catalog that displays all the different configurations, models, and accessories sold with this Delta-Rockwell-Milwaukee 14″ drill press. This manual covers many drill press models. The following a few of the known model numbers covered in this drill press manual: 989, 999, 1289, 1300, 1302, 14-005, 14-006, 14-007, 14-008, 14-205, 14-206, 14-207, 14-208, 14-210, 14-211, 14-212, 14-213 I also highly recommend the “DELTA Getting the Most Out of Your Drill Press Manual”, which we carry. It covers a lot of different set ups and unique uses for these drill presses. Contents: Motors and Speeds…………………………….1 Table Adjustments…………………………….1 Spindle Adjustments…………………………..2 Adjusting Spindle-Return Spring………………..2 How to Change Spindle…………………………2 Mortising Attachment………………………….3 Diagram of Mortising Attachment………………..3 Lubrication………………………………….4 Parts Diagram………………………………..4 Parts List…………………………………..5 Overview: I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.Visit our eBay Store!We have over 1,100 manuals available. From our shop to yours. We get this. But you get this! Why settle for anything less?We can’t make pictures a lot better than the original, but we can fix everything else. Shipping: We ship every M-T-W-T-F except US holidays. All of our manuals are shipped with Delivery Confirmation. We stamp “Do Not Bend” on them to ensure that your manual arrives quickly in good condition. Any package that weighs more than 15.9 oz cannot be shipped First Class, and will be shipped Media Mail. Priority and Express mail options are available to purchase. Since we offer free shipping, we cannot reship manuals for free, due to inaccurate or insufficient addresses. Reshipping Fees for inaccurate or insufficient addresses: $5.00 for the first manual and $2.50 for each additional manual. Service: We have been providing this service to fellow craftsman and machinist for over 20 years. We treat everyone as we would like to be treated. We try to take care of all our customers. We do more than sell manuals, we have a complete woodworking and machine shop. We operate all kinds of machinery everyday.
