CRAFTSMAN-SEARS 15″ 1/2 Heavy Duty Drill Press 113.24520 Parts Manual 0193
Manual Description: Number of Pages: 24 This is a reproduction, not a photocopy, of an original Sears Craftsman Heavy Duty 15-1/2 Inch Drill Press Owners Manual and Parts for model number 113.24520. This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list and exploded views and adjustments. This is one of the most complete manuals for a drill press that I have seen out there. One of the important things that the manual covers is how to remove and reinstall the chuck. This manual has a great description on setting up and aligning the pulleys and motor. There is also a detailed description on adjusting the quill spring with diagrams. This is a great drill press which I have personally owned and operated for over 30 years. You shouldn’t let its little belt drive fool you, it will drill up to 2 inch holes with a spade bit. Contents:Safety and General Information…………………………1-5 Motor Specifications and Electrical………………………5 Assembly…………………………………………….6&7 Chuck Installation……………………………………..7 Installing Depth Stop…………………………………..8 Raising the Head……………………………………..8&9 Installing Motor Pulley………………………………9&10 Installing Motor………………………………………10 Aligning Motor and Pulley………………………………11 General Information and Know Your Drill Press………….12-14 Removing Quill………………………………………..14 Basic Drill Operation……………………………….15&16 Adjustments…………………………………………..17 Adjusting Quill Spring…………………………………18 Troubleshooting……………………………………….19 Parts List and Diagrams……………………………..20-24 Overview: I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.Visit our eBay Store!We have over 1,100 manuals available. From our shop to yours. We get this. But you get this! Why settle for anything less?We can’t make pictures a lot better than the original, but we can fix everything else. Shipping: We ship every M-T-W-T-F except US holidays. All of our manuals are shipped with Delivery Confirmation. We stamp “Do Not Bend” on them to ensure that your manual arrives quickly in good condition. Any package that weighs more than 15.9 oz cannot be shipped First Class, and will be shipped Media Mail. Priority and Express mail options are available to purchase. Since we offer free shipping, we cannot reship manuals for free, due to inaccurate or insufficient addresses. Reshipping Fees for inaccurate or insufficient addresses: $5.00 for the first manual and $2.50 for each additional manual. Service: We have been providing this service to fellow craftsman and machinist for over 20 years. We treat everyone as we would like to be treated. We try to take care of all our customers. We do more than sell manuals, we have a complete woodworking and machine shop. We operate all kinds of machinery everyday.
